Experience racing like never before with MOZA’s Xbox Licensed R3 Racing Bundle. This bundle sets the benchmark for entry-level racing, featuring a powerful 3.9Nm DD Servo Motor, aviation-grade aluminum construction, and durable ISF PU grips. Enjoy ultra-low torque ripple, mobile app control, and compatibility with top racing games like Forza Horizon and F1. With an innovative X-shaped design, intelligent temperature control, and customizable features, the R3 delivers immersive feedback and precision. Officially licensed for Xbox, this bundle merges console performance with MOZA’s Direct Drive technology. Elevate your racing setup with the MOZA R3 Racing Bundle.

Overview >

Product variants

Model: For Xbox & PC

Upgrade Your Racing Experience

SR-P Lite Clutch Pedal

$42.90

Performance Kit for SR-P Lite

$29.00

12-inch Round Wheel Mod for ESX

$69.00 $79.00

ES Formula Wheel Mod

$39.00

Usually ship within 3 business days.

14-Day Returns Policy

Up to 24-Month Warranty Protection

Fast Shipping from US Warehouse

Pairs well with

R3 Racing Wheel and Pedals for Xbox & PC

Usually ship within 3 business days.

$359.00

At a Glance

MOZA's First XBOX Licensed Racing Bundle

MOZA Racing have collaborated with Microsoft to create our first officially licensed, fully plug and play bundle for Xbox Series X|S and Xbox One.

3.9Nm Direct Drive Power

Feel every turn, bump, and drift with ultra-responsive direct drive force feedback for a truly immersive racing experience.

Xbox-Ready Racing Wheel with Pro Features

Officially licensed for Xbox, the MOZA ES Wheel features a durable aluminum rim, grippy ISF PU handles, 22 customizable buttons, and a quick-release system — all engineered for immersive, console-ready sim racing.

Dual-Pedal Set with Pro-Level Precision

Constructed from high-strength steel, the SR-P Lite Pedals deliver reliable performance with adjustable spacing, non-slip stability, and maintenance-free Hall sensors — built for both beginners and serious racers.

Learn More

SPECS

MOZA R3 DD Base

Drive Type: Direct Drive
Max Wheel Rotation: Limitless
Housing Material: Aviation Aluminum Alloy
Color: Black
Peak Torque: 3.9 Nm
Rated Power: 60W
Input Voltage: 110V~220V AC —>12V DC
Encoder Resolution: 15 bits
USB Refresh Rate: 1000Hz
APP Functionality: Supported
Quick Release: Supported
Connection Ports: Power, DC Input, Pedal, USB, Dash
Accessories: Manual and Warranty Card, Power Supply, Data Cable, Toolkit
Mounting Method: 4 holes on the bottom
Table Clamp: Included
Online Firmware Upgrade: Supported

ESX Steering Wheel

Grips: ISF PU
Face Plate Material: Aluminum Alloy
Shifter Paddle Material: Aluminum Alloy
Size: 280mm
Buttons: 22
RPM LED Light: 10 High Brightness LED RGB Beads
Intelligent Telemetry: Supported
Fully Adjustable RPM LEDS through MOZA Pit House: Supported
Release Method: MOZA Quick Release

SR-P Lite Pedals

Material: High-strength Steel
Plate Material: High-strength Steel
Color: Black
Throttle Sensor: Hall Sensor
Pedal Spacing: Adjustable
Pedal Plate Height: Adjustable
Pedal Input Adjustment: Supported
Pedal Input Reversal: Supported
Pedal Output Curve Adjustment: Supported

User Manual

MOZA R3 Bundle User Manual>

WHAT'S INBOX

R3 DD Base * 1
ESX Steering Wheel * 1
SR-P Lite Pedals (No Clutch) * 1
Table Clamp * 1
Power Adapter
Power Cord
USB Cable
Toolkit
User Manual
Warranty Card

FAQs

Still have questions? Get help from a MOZA expert.

Is the MOZA R3 Racing Bundle compatible with my system?

Yes. The MOZA R3 Racing Bundle (Xbox & PC version) is officially licensed for Xbox Series X|S and also works with Windows 10/11 PCs. On Xbox, it supports popular titles such as Forza Horizon 5, Forza Motorsport, and the F1 series. On PC, it is compatible with many leading sim racing titles. Simply connect the R3 to your console or PC, and you’re ready to race—no additional adapters required.

Does the R3 deliver strong force feedback for serious sim racing?

Absolutely. The R3 features a direct drive motor with 3.9Nm of peak torque—offering significantly more precision and road feel than gear or belt-driven systems. Whether you’re a casual gamer or an experienced sim racer, you’ll enjoy smooth, detailed feedback and a more immersive driving experience.

What’s included in the bundle? Do I need anything else to start racing?

The bundle includes everything you need to start racing right away:

R3 Direct Drive Wheelbase
MOZA ESX Steering Wheel (Xbox licensed)
SR-P Lite Pedals
Table clamp mounting kit

It works right out of the box—no cockpit required. For a more immersive setup, it can also be mounted to a sim racing rig.

Can I customize settings like force feedback and pedal sensitivity?

Yes! Using the MOZA Pit House software on PC, you can fine-tune force feedback strength, button mappings, pedal dead zones, and more. On Xbox, you can also adjust many in-game settings to match your driving style. Firmware updates ensure your equipment stays at peak performance.

What is the warranty policy for the MOZA R3 Racing Bundle?

At MOZA Racing, we offer a limited warranty for each component of the R3 Racing Bundle based on its category:

R3 Direct Drive Wheelbase:

Main body – 24 months
Power supply – 12 months
Cable – 6 months

ES Steering Wheel:

Main body – 12 months

SR-P Lite Pedals:

Main body – 12 months
Cable – 6 months

Table Clamp & Accessories: Not covered under warranty

We’re committed to supporting our customers with reliable service. If warranty service is required and approved, customers are responsible for shipping the product back to us. For full warranty terms and conditions, please visit our Warranty Policy.

amazing

Great starter sim racing bundle. This is an amazing choice if you are new to the hobby and not completely sure if you want to fully invest in a high torque base and loadcell pedals.
Pros:
3.9 NM Torque. More than other competitors such as the Logitech G29/G920.
Pedals included.
Stickers!
Decent wheel included (ESX) which is good enough for starting out.

Cons:
3.9 NM Torque. This was a pro as well but there are many competitors from other companies and even MOZA themselves (the R5) that give better force feedback for a little more money.
The pedals are very VERY entry level. They can be upgraded but I would recommend upgrading to a whole new set of pedals instead of adding on to them. There is no way to add a Load cell without third-party devices.

A great choice for beginners. This was my introduction into the sim racing world, and my setup has evolved a lot since then (I bought the R3 in Summer 2024).
